2. Technical specifications
2.1. Ultimate rated value
| Parameter | Symbol | Range | Unit |
| Simulate power supply voltage | VDO | -0.3 ~ 6.0 | V |
| Digital Supply voltage | VDOF | -0.3 ~ 2.2 | V |
| Working temperature range | -40 ~125 | ℃ | |
| Storage Temperature Range | -50 ~150 | ℃ | |
| Junction temperature | 150 | ℃ | |
| ESD range | HBM | 4KV | V |
Note: Exceeding the absolute maximum rated value may cause permanent damage, and prolonged operation at the above absolute maximum rated value may affect the reliability of the device.
2.1. Electrical parameters
Table 1 Working characteristics (VS=5.0 Vdc, TA=25 ° C unless otherwise specified)
| Characteristic | Sign | Minimum | Typical values | Maximum | Unit |
| Voltage | VS | 4.75 | 5 | 5.25 | Vdc |
| Power supply current | Io | — | 3 | mAdc | |
| Minimum pressure output (0 ℃ to 85 ℃) VS=5.0 V | Voff | 0.4 | 0.5 | 0.6 | Vdc |
| Full range output (0 ℃ to 85 ℃) VS=5.0 volts | VFSO | 4.4 | 4.5 | 4.6 | Vdc |
| Full range (0 ℃ to 85 ℃) VS=5.0 volts | VFSS | 3.8 | 4 | 4.2 | Vdc |
| Accuracy (0 ℃ to 85 ℃) | — | — | — | 2.5 | %VFSS |
| Characteristic | Sign | Minimum | Typical values | Maximum | Unit |
| Response time | tR | — | 1 | — | ms |
| Soak time | — | — | 100 | — | ms |
| ESD protection | — | — | 4 | — | kV |
